质量在我手中,用户在我心中
test water meter
LXSL-15~25ELXSYL-15~25testwatermeter 1)Use:Recordthetotalamountofcoldwaterflowingthroughthetapwaterpipe.2)Features:Verticalwatermeterscanbeinstalledverticallyonthepipe,andotherfeaturesaresimilartoE-typeandsemi-liquidseals.3)Conditionsofuse:a.Conditionsofuse:watertemperature≤30°Cwaterpressure≤1Mpab.Indicationerror:ThemaximumerrorofthecoldwatermeterbetweentheoverloadflowQ4andtheboundaryflowQ2is:Q2%,themaximumerror±5%betweentheboundaryflowQ2andtheminimumflowQ1(excludingtheboundaryflowQ2)Note:Theperformanceindicatorsofwatermetersareinlinewith丨SO4064internationalstandardandGB/T778.1-3-2007nationalstandard.
关键字
Vertical screw-wing water meter
1)use:
Record the total amount of cold water that flows through the tap water pipe.
2)Characteristics:
· Easy to repair with detachable movement
· Magnetic transmission dry structure ensures that the counter is clean and clear
· Low starting flow and high sensitivity
· Internal adjustment structure to effectively prevent private adjustment
· Built-in stainless steel filter for user convenience
· Bearing system made of special wear-resistant material ensures longer life of the water meter
· Can be equipped with a remote transmission counter
Note: The performance index of water meter complies with 1S04064 international standard and GB/T 778.1~3-2007 national standard.
3)The main parameters:
a、Conditions of Use:Water temperature≤≌30°C
Water pressure≤1.6Mpa
b、Cold water type water meter working temperature is less than 50°C
Hot water type water meter working temperature is less than 90°C
c、Indication error: the maximum error of the cold water meter between the overload flow Q4 and the boundary flow Q2 is 2% of the soil, between the boundary flow Q2 and the minimum flow Q1 (excluding the boundary flow Q2), the maximum error soil 5%
4)There is a liquid seal type to choose from.
5)There is a flood control type water meter to choose from.
Record the total amount of cold water that flows through the tap water pipe.
2)Characteristics:
· Easy to repair with detachable movement
· Magnetic transmission dry structure ensures that the counter is clean and clear
· Low starting flow and high sensitivity
· Internal adjustment structure to effectively prevent private adjustment
· Built-in stainless steel filter for user convenience
· Bearing system made of special wear-resistant material ensures longer life of the water meter
· Can be equipped with a remote transmission counter
Note: The performance index of water meter complies with 1S04064 international standard and GB/T 778.1~3-2007 national standard.
3)The main parameters:
a、Conditions of Use:Water temperature≤≌30°C
Water pressure≤1.6Mpa
b、Cold water type water meter working temperature is less than 50°C
Hot water type water meter working temperature is less than 90°C
c、Indication error: the maximum error of the cold water meter between the overload flow Q4 and the boundary flow Q2 is 2% of the soil, between the boundary flow Q2 and the minimum flow Q1 (excluding the boundary flow Q2), the maximum error soil 5%
4)There is a liquid seal type to choose from.
5)There is a flood control type water meter to choose from.
关键字
Rotor type semi-liquid sealing water meter
LXSY-15~50 rotary semi-liquid sealing water meter
1) Use:
Record the total amount of cold water that flows through the tap water pipe.
2) Features:
The water wheel of the water meter is packaged in a special liquid, and the pointer part is filled with water for a long time to keep the reading clear for a long time. It has the characteristics of convenient reading, good anti-fouling and beautiful appearance. It is especially suitable for domestic use.
3) Main parameters:
a. Conditions of use: water temperature ≤ 30°C Water pressure ≤1Mpa
b. Indication error: The maximum error of the cold water meter between the overload flow tQ4 and the boundary flow 1Q2 is ±2%, and the maximum error is 5% between the boundary flow Q2 and the minimum flow Q1 (excluding the boundary flow ± Q2).
Note:
a. The performance index of water meter complies with ISO4064 international standard and GB/T 778.1 ~3-2007 national standard.
b, LXSY-15~25 has a molded case water meter and a highly sensitive water meter.
C. The starting flow of the high-sensitivity water meter can be less than 2Lh.
1) Use:
Record the total amount of cold water that flows through the tap water pipe.
2) Features:
The water wheel of the water meter is packaged in a special liquid, and the pointer part is filled with water for a long time to keep the reading clear for a long time. It has the characteristics of convenient reading, good anti-fouling and beautiful appearance. It is especially suitable for domestic use.
3) Main parameters:
a. Conditions of use: water temperature ≤ 30°C Water pressure ≤1Mpa
b. Indication error: The maximum error of the cold water meter between the overload flow tQ4 and the boundary flow 1Q2 is ±2%, and the maximum error is 5% between the boundary flow Q2 and the minimum flow Q1 (excluding the boundary flow ± Q2).
Note:
a. The performance index of water meter complies with ISO4064 international standard and GB/T 778.1 ~3-2007 national standard.
b, LXSY-15~25 has a molded case water meter and a highly sensitive water meter.
C. The starting flow of the high-sensitivity water meter can be less than 2Lh.
关键字
